Product Features

Vision Sensor Features Configuration tool Applications System configuration Vision sensor External dimensions

Concept

The vision sensor is the key device on the shop floor that detects data necessary for e-F@ctory in real time. Mitsubishi Electric vision sensors which support CC-Link IE Field Network Basic and SLMP*1 are highly compatible with Mitsubishi Electric factory automation products. Measuring results are seamlessly coordinated with the edge computing level, realizing smooth analysis for reducing TCO*2.

*1. Seamless Message Protocol
*2. Total Cost of Ownership

VS80

VS80

More details

Equipped with PatMax RedLine®*3, the VS80 can identify works traveling at high speed. Its compact footprint easily fits into space-constrained area, hard-to-reach area, and is installable on the robot hands. PoE equipped stand-alone vision sensor with reduced wiring. Monochrome modeles and color modeles are available.

*3. High-speed/high-accuracy pattern matching algorithm

VS70

VS70

More details

Equipped with PatMax RedLine®, the VS70 can identify works traveling at high speed. Lightings, lenses, and filters can be selected from a wide range of option products, allowing customization according to customer requirements. Monochrome modeles and color modeles are available.

VS20

VS20

More details

Simple presence/absence checks can be done. Monochrome modeles and color modeles which support color verification are available. Even novice users can make a setting easily and quickly. The design can be changed between in-line and right-angle according to the installation space.

Specifications/functions comparison
ItemVS80VS70VS20
ImageryMonochrome/colorMonochrome/colorMonochrome/color
Lighting/filter–IntegratedIntegrated
Protective structureIP40IP67IP65
Autofocus–●–
PoE adapter●––
Presence/absence●●●
Measurement●●●*4
Location*5●●–
OCR/OCV*6●●–
Code reading●●–
Geometry●●–
*4: Excluding some models
*5: Function to output position information of the detected work.
*6: Alphabet and numeral reading


page top

Vision Sensor Features Configuration tool Applications System configuration Vision sensor External dimensions
