Product Features
Vision sensor VS80
Autofocus module equipped*1
Autofocus module brings a camera into focus easily, reducing time for initial setting and set-up change. Even when installing the camera in a hard-to-reach space, it is easy to bring the camera into focus.
*1. Manual focus lenses are also available.
Water-proof/dust-proof
The product complies with IP67 rating, dust-proof and water-proof performance are assured.
Product lineup
Select products according to applications.
■Monochrome
| Item | VS70M-600 VS70M-600-□ | VS70M-800 VS70M-800-□ | VS70M-802 VS70M-802-□ | |
|---|---|---|---|---|
| Image resolution (pixels) | 640 × 480 | ● | ● | – |
| 800 × 600 | ● | ● | – | |
| 1600 × 1200 | – | – | ● | |
| Maximum image acquisition speed (frame/s) | When image resolution is set to 640 × 480: 217 When image resolution is set to 800 × 600: 165 | 53 | ||
| Processor performance*2 (times) | 1 | 1.25 | 1.25 | |
| PatMax RedLine® | VS70M-□-R, VS70M-□-ER: supported VS70M-□, VS70M-□-E: not supported*3 | |||
| EasyBuilder | ● | ● | ● | |
| Spreadsheet | VS70M-□, VS70M-□-R: supported VS70M-□-E, VS70M-□-ER: not supported*3 | |||
■Color
| Item | VS70C-600-R | VS70C-800-R | VS70C-802-R | |
|---|---|---|---|---|
| Image resolution (pixels) | 640 × 480 | ● | ● | – |
| 800 × 600 | ● | ● | – | |
| 1600 × 1200 | – | – | ● | |
| Maximum image acquisition speed (frame/s) | When image resolution is set to 640 × 480: 135 When image resolution is set to 800 × 600: 100 | 33 | ||
| Processor performance*2 (times) | 1 | 1.25 | 1.25 | |
| PatMax RedLine® | Supported | |||
| EasyBuilder | ● | ● | ● | |
| Spreadsheet | Supported | |||
- *2. Magnification based on the VS70M-600-E
- *3. Please refer to Product list for details.
Working distance
The distance from a lens to an inspection target is referred to as "working distance", and an area where a vision sensor can see at that distance is referred to as "field of view".
