Motion Controllers Product Lines
Number of axes
Operation cycle
Motion module
RD78GH
RD78G
CC-Link IE TSN
Superior motion module
Superior motion module
Up to
256 axes
256 axes
From
31.25 μs
31.25 μs
Motion controller
Simple Motion module
RD77MS
SSCNETIII/H
Superior motion control
Superior motion control
Up to
16 axes
16 axes
From
0.444 ms
0.444 ms
RD77GF
CC-Link IE Field
Simple Motion module
Simple Motion module
Up to
32 axes
32 axes
From
0.5 ms
0.5 ms
Number of axes
Operation cycle
Motion module
FX5-80SSC-G
FX5-40SSC-G
CC-Link IE TSN
Superior motion module
Superior motion module
Up to
8 axes
8 axes
From
500 μs
500 μs
Simple Motion module
FX5-80SSC-S
FX5-40SSC-S
Superior motion control
with easy settings
with easy settings
Up to
8 axes
8 axes
From
0.888 ms
0.888 ms
Number of axes
Operation cycle
Motion controller
Stand-alone Motion controller
Q170MSCPU
Ideal for small scale system
Up to
16 axes
16 axes
From
0.222 ms
0.222 ms
Simple Motion module
QD77MS
QD77MS SSCNETIII/H
Motion control
Motion control
Up to
16 axes
16 axes
From
0.888 ms
0.888 ms
QD77GF
CC-Link IE Field
motion control
motion control
Up to
16 axes
16 axes
From
1.0 ms
1.0 ms
Number of axes
Operation cycle
Embedded type servo system controllers
MR-EM441G
High-speed motion control in
an industrial personal computer environment.
an industrial personal computer environment.
Up to
64 axes
64 axes
From
62.5 μs
62.5 μs
MR-EM340GF
Motion control on IPC environment with CC-Link IE Field Network
Up to
16 axes
16 axes
From
0.5 ms
0.5 ms
MR-MC341
MR-MC200 Series
Servo system in a combination with a C Controller
Up to
64 axes
64 axes
From
0.22 ms
0.22 ms
Q173SCCF
Servo system by embedding the Position board in a PC
Up to
20 axes
20 axes
From
0.22 ms
0.22 ms
Number of axes
Operation cycle
Motion Control Software
SWM-G
Software-based controller for
high-precision motion control.
high-precision motion control.
Up to
128 axes
128 axes
From
125 μs
125 μs
Sensing module
MR-MT2000 Series
High Speed and High Accuracy by Synchronization of I/O Signals with Motion Control
Optical Hub Unit
MR-MV200
SSCNETIII/H compatible network hub unit
